Redundancy Climate Systems for IT, Server & Process Cooling

Installation kit for small and large split air conditioning systems, primarily for commercial applications, consisting of the following individual components in the corresponding quantities and for a maximum rated air conditioning output of approximately 12 kW. Installation set – basic equipment: DE-WU0862104001 – 4x M8 quick-release fasteners DE-WU04223830 – 4x M8 rubber washers DE-WU04168 – 4x M8 housing washers DE-WU0057850 – 4x M8x40 machine screws DE-WU0892143 – 1x PURLOGIC® Easy-Mounting foam DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml DE-WU05021413 – 6x cable ties KBL 1 made of polyamide with plastic tongue DE-HS1001 – 3 m control cable 5 x 1.5 mm DE-WU097366090 – 3 m cable duct 60 x 90 mm, white DE-HS760002001 – 3 m PVC-U pipe 20 mm DE-HS760010001 – 1x PVC-U angle 20 mm, 90° DE-HS240016001 – 1x Tangit glue DE-WU0176204560 – 20x TX screws 4.5x60mm DE-WU590620635 - 20x dowels 6mm DE-WU0176203535 - 2x TX screws 3x35mm DE-S321.4016 - 3m CU double pipe 10, 16mm insulated DE-S282.0541 - 2x solder sockets 10 mm DE-S282.0543 – 2x solder sockets 16 mm 1x nitrogen flat rate, soldering gas, sealant Mounting kit variant 1 – For facades with a cooling capacity over 3.5 kW: DE-WU0862009062 – 2x wall brackets 630 mm DE-WU0862005006 – 2x end caps DE-WU0862009125 – 2x bracket 45° DE-WU0862005326 – 2x retaining clips clamp DE-WU005791040 – 2x hexagon screw M10 DE-WU037110 – 2x hexagon nut M10 DE-WU590681266 – 6x Universal wall anchor 12 mm DE-WU019210100 – 6x Hex bolts M10x100 DE-WU041610 – 6x Washers M10 Mounting kit variant 2 – For floor or flat roof mounting: DE-LIN1229000 - 1x SET roof support beam 1000 mm DE-WU071392915 – 2x Construction site protection mats in strips

Installation set for small and large split air conditioning systems, primarily for residential use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW. Installation Set – Basic Equipment: DE-WU0862104001 – 4x M8 quick connectors DE-WU04223830 – 4x M8 rubber washers DE-WU04168 – 4x M8 housing washers DE-WU0057850 – 4x M8x40 machine screws DE-WU0892143 – 1x PURLOGIC® mounting foam DE-WU0892165 – 1x white acrylic sealant – 310 ml DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml DE-WU05021413 – 6x cable ties KBL 1 made of polyamide with plastic tongue DE-HS1001 – 5 m control cable 5 x 1.5 mm DE-WU097366090 – 5 m cable duct 60 x 90 mm, white DE-HS760002001 – 5 m PVC-U pipe 20 mm DE-HS760010001 – 1x PVC-U elbow 20 mm 90° DE-HS240016001 – 1x Tangit adhesive DE-WU0176204560 – 30x TX screws 4.5x60 mm DE-WU590620635 – 32x wall plugs 6 mm DE-WU0176203535 – 2x TX screws 3x35 mm DE-S321.4046 – 5 m CU double pipe 6, 12 mm insulated DE-S282.0540 – 2x solder sleeves 6 mm DE-S282.0542 – 2x solder sleeves 12 mm 1x nitrogen soldering gas (flat rate) content, sealant Installation Set Variant 1 – For facades from 3.5 kW cooling capacity: DE-WU0862009062 - 2x wall bracket 630 mm DE-WU0862005006 – 2x end caps DE-WU0862009125 - 2x support beams 45° DE-WU0862005326 - 2x holding clamp M10 DE-WU005791040 - 2x hex screw M10 DE-WU037110 - 2x hex lock nut M10 DE-WU041610 - 6x body washers M10 DE-WU590681266 – 6x universal wall plugs 12 mm DE-WU019210100 – 6x hex screws M10x100 DE-WU041610 – 6x washers M10 Installation Set Variant 2 – For floor or flat roof installation: DE-LIN1229000 - 1x SET roof support beams 1000 mm DE-WU071392915 – 2x construction site protective mats (strips)

Installation set for small and large split air conditioning systems, primarily for commercial use, consisting of the following components in the specified quantities and for a maximum nominal capacity of approx. 12 kW. Installation Set – Basic Equipment: DE-WU0862104001 – 4x M8 quick connectors DE-WU04223830 – 4x M8 rubber washers DE-WU04168 – 4x M8 housing washers DE-WU0057850 – 4x M8x40 machine screws DE-WU0892143 – 1x PURLOGIC® mounting foam DE-WU0892165 – 1x white acrylic sealant – 310 ml DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml DE-WU05021413 – 12x cable ties KBL 1 made of polyamide with plastic tongue DE-HS1001 – 10 m control cable 5 x 1.5 mm DE-WU097366090 – 10 m cable duct 60 x 90 mm, white DE-HS760002001 – 10 m PVC-U pipe 20 mm DE-HS760010001 – 1x PVC-U elbow 20 mm 90° DE-HS240016001 – 1x Tangit adhesive DE-WU0176204560 – 30x TX screws 4.5x60 mm DE-WU590620635 – 32x wall plugs 6 mm DE-WU0176203535 – 2x TX screws 3x35 mm DE-S321.4016 – 10 m CU double pipe 10, 16 mm insulated DE-S282.0541 – 2x solder fittings 10 mm DE-S282.0543 – 2x solder fittings 16 mm 1x nitrogen soldering gas (flat rate) content, sealant Installation Set Variant 1 – For facades from 3.5 kW cooling capacity: DE-WU0862009062 – 2x wall brackets 630 mm DE-WU0862005006 – 2x end caps DE-WU0862009125 – 2x support beams 45° DE-WU0862005326 – 2x holding clamp M10 DE-WU005791040 – 2x hex screws M10 DE-WU037110 – 2x hex lock nuts M10 DE-WU041610 – 4x body washers M10 DE-WU590681266 – 6x universal wall plugs 12 mm DE-WU019210100 – 6x hex screws M10x100 DE-WU041610 – 6x washers M10 Installation Set Variant 2 – For floor or flat roof installation: DE-LIN1229000 - 1x SET roof support beams 1000 mm DE-WU071392915 – 2x construction site protective mats (strips)

Installation set for small and large split air conditioning units, primarily for commercial use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW. Installation Set – Basic Equipment: DE-WU0862104001 – 4x M8 quick couplings DE-WU04223830 – 4x M8 rubber washers DE-WU04168 – 4x M8 housing washers DE-WU0057850 – 4x M8x40 machine screws DE-WU0892143 – 1x PURLOGIC® mounting foam DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml DE-WU05021413 – 12x cable ties KBL 1 polyamide with plastic tongue DE-HS1001 – 15 m control cable 5 x 1.5 mm² DE-WU097366090 – 15 m cable trunking 60 x 90 mm, white DE-HS760002001 – 15 m PVC-U pipe 20 mm DE-HS760010001 – 1x PVC-U elbow 20 mm 90° DE-HS240016001 – 1x Tangit adhesive DE-WU0176204560 – 40x TX screws 4.5x60mm DE-WU590620635 – 42x wall plugs 6mm DE-WU0176203535 – 2x TX screws 3x35mm DE-S321.4016 – 15 m CU double pipe 10,16mm insulated DE-S282.0541 – 2x solder fittings 10mm DE-S282.0543 – 2x solder fittings 16mm 1x nitrogen soldering gas (flat rate), sealant included Installation Set Variant 1 – For facades from 3.5 kW cooling capacity: DE-WU0862009062 – 2x wall brackets 630mm DE-WU0862005006 – 2x end caps DE-WU0862009125 – 2x support bars 45° DE-WU0862005326 – 2x retaining clips M10 DE-WU005791040 – 2x hex screws M10 DE-WU037110 – 2x hex lock nuts M10 DE-WU041610 – 4x fender washers M10 DE-WU590681266 – 6x universal wall plugs 12 mm DE-WU019210100 – 6x hex screws M10x100 DE-WU041610 – 6x washers M10 Installation Set Variant 2 – For floor or flat roof mounting: DE-LIN1229000 - 1x SET roof support beams 1000mm DE-WU071392915 – 2x construction protection mats (strips)

Installation set for small and large split air conditioning units, primarily for commercial use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW. Installation Set – Basic Equipment: DE-WU0862104001 – 4x M8 quick couplings DE-WU04223830 – 4x M8 rubber washers DE-WU04168 – 4x M8 housing washers DE-WU0057850 – 4x M8x40 machine screws DE-WU0892143 – 1x PURLOGIC® mounting foam DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml DE-WU05021413 – 20x cable ties KBL 1 polyamide with plastic tongue DE-HS1001 – 20 m control cable 5 x 1.5 mm² DE-WU097366090 – 20 m cable trunking 60 x 90 mm, white DE-HS760002001 – 20 m PVC-U pipe 20 mm DE-HS760010001 – 1x PVC-U elbow 20 mm 90° DE-HS240016001 – 1x Tangit adhesive DE-WU0176204560 – 50x TX screws 4.5x60mm DE-WU590620635 – 52x wall plugs 6mm DE-WU0176203535 – 2x TX screws 3x35mm DE-S321.4016 – 20 m CU double pipe 10,16mm insulated DE-S282.0541 – 2x solder fittings 10mm DE-S282.0543 – 2x solder fittings 16mm 1x nitrogen soldering gas (flat rate), sealant included Installation Set Variant 1 – For facades from 3.5 kW cooling capacity: DE-WU0862009062 – 2x wall brackets 630mm DE-WU0862005006 – 2x end caps DE-WU0862009125 – 2x support bars 45° DE-WU0862005326 – 2x retaining clips M10 DE-WU005791040 – 2x hex screws M10 DE-WU037110 – 2x hex lock nuts M10 DE-WU041610 – 4x fender washers M10 DE-WU590681266 – 6x universal wall plugs 12 mm DE-WU019210100 – 6x hex screws M10x100 DE-WU041610 – 6x washers M10 Installation Set Variant 2 – For floor or flat roof mounting: DE-LIN1229000 - 1x SET roof support beams 1000mm DE-WU071392915 – 2x construction protection mats (strips)

This roof inlet is designed for the safe and reliable routing of cables and wires on flat roofs. Its corrosion-resistant construction ensures long-term durability without rust or leakage. The wide base surface allows for a secure and watertight connection to the roof membrane. Manufactured from lightweight 2 mm aluminium plate, the unit combines structural stability with ease of installation. The interior is smoothly rounded beneath the protective hood to protect cables and insulation coatings from mechanical damage. With a generous passage opening of 125 × 125 mm and a height of 600 mm, the roof inlet provides ample space for organised and protected cable routing. For enhanced thermal insulation and condensation protection, optional insulation using Armaflex® insulation materials and technical foam is available. This optional insulation improves energy efficiency and provides additional protection for sensitive cables and conduits, particularly in demanding climatic conditions. Technical Specifications Application: Cable and wire routing on flat roofs Material: Aluminium, 2 mm thickness Corrosion resistance: Rust-free Passage opening: 200 × 200 mm Height: 600 mm Base dimensions: 425 × 425 mm Optional: Mandatory Armaflex® and/or PU-Foam Insulation after installation.

Installation set for anchoring of usual two-point consoles with supporting trusses, primarily for installing appliances in commercial use on insulated facades with External Thermal Insulation Composite System. This SET is consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approximately 12 kW and thickness of insulation of upt o 200mm max. Installation Set – For ETICS thickness from 100 - 200 mm: DE-WU0892165 – 1x acrylic sealant white – 310 ml DE-WU0903450205 – 3x Allround Injection Mortar WIT-VM 250 – 420 ml DE-WU090344121 - 6x 12x50mm Sieve sleeve anchor - Perforated brickwork, aerated concrete DE-WU0905461016 - 6x M10x260mm Anchor rod for injection system DE-WU041610 – 12x M10x30mm fender washer DE-WU031710 – 12x hex nuts M10 DE-WU0911100200 - 6x Distance Spacer Installation AMO MAX

This roof inlet is designed for the safe and reliable routing of cables and wires on flat roofs. Its corrosion-resistant construction ensures long-term durability without rust or leakage. The wide base surface allows for a secure and watertight connection to the roof membrane. Manufactured from lightweight 2 mm aluminium plate, the unit combines structural stability with ease of installation. The interior is smoothly rounded beneath the protective hood to protect cables and insulation coatings from mechanical damage. With a generous passage opening of 500 × 200 mm and a height of 600 mm, the roof inlet provides ample space for organised and protected cable routing. For enhanced thermal insulation and condensation protection, optional insulation using Armaflex® insulation materials and technical foam is available. This optional insulation improves energy efficiency and provides additional protection for sensitive cables and conduits, particularly in demanding climatic conditions. Technical Specifications Application: Cable and wire routing on flat roofs Material: Aluminium, 2 mm thickness Corrosion resistance: Rust-free Passage opening: 500 × 200 mm Height: 600 mm Base dimensions: 680 × 425 mm Optional: Mandatory Armaflex® and/or PU-Foam Insulation after installation.

Efficient vibration damping reduces vibrations and noise during the installation of technical equipment.  Durable material consisting of robust and weather-resistant SBR rubber for maximum service life. Easy installation enables quick and secure mounting with versatile application possibilities. High load-bearing capacity and stability ensure reliable performance under various requirements. Low-maintenance properties offer resistance to weathering, UV radiation, and many chemicals. Ideal for safe and long-lasting use in building technology and air conditioning installation. Note The damping bases with article numbers 0862003052, 0862003053, 0862003054, 0862003055, 0862003056, 0862003057 are not compatible with the risers 0862003138 and 0862003139. Our damping bases are specifically designed for professional use in building technology and air conditioning systems. They minimize noise and vibration transmission, contributing to quieter and more efficient system operation. Thanks to their robust material quality, they are ideal for long-term use under demanding conditions.

Suitable for heavy and normal loads Suitable for: Heavy and normal loads.Min. coefficient of friction: 0.6 µMaterial thickness: 8 mmTemperature range: -40 to 115 °CMaterial: Rubber granules bonded with PURColor: BlackWidth: 250 mmLength: 5000 mmWeight per m²: 6.88 kgDensity: 860 kg/m³Min. elongation at break: 60%Building material class / condition: E - Normally flammable / according to DIN EN 13501-1 Type name: REGUPOL cargo mat 7210

Standard mounting beam – 1000 mm set (2 pieces incl. bolts). Robust PVC mounting block for all types of outdoor units. UV- and high-temperature resistant, with a load capacity of up to 450 kg/m (static). Delivered with fastening bolts. Ideal for structured cable management and secure installation with very low additional weight. This set is mainly used for proper installation of split air-conditioning outdoor units as well as cable trays on flat roofs. Color: BlackWeight: 1.5 kg Contents: 1 set (2 pieces incl. bolts) Perfect for durable and secure mounting of outdoor units.

The Big Foot Multi Frame XL Extension is a robust and versatile extension for flat roof mounting systems. Designed for easy assembly, it supports a wide variety of units while maintaining full roof functionality. Each of the two support feet measures 330x330 mm and is individually height-adjustable from 330 to 610 mm, allowing precise alignment on uneven surfaces. The large footplates ensure even load distribution and protect the roof surface. With a maximum load capacity of 500 kg, the extension is suitable for demanding applications. Supplied boxed with clamp kits, it features hot-dipped galvanized steel construction, recyclable EPDM foam mats, and recycled glass-filled nylon feet. Salt spray tested to 1000 hours. Technical features: Compatible with a wide variety of units Feet dimensions: 330 x 330 mm Height adjustment: 330–610 mm Maximum load: 500 kg Simple to assemble Supplied boxed with clamp kits Hot-dipped galvanized steel Recyclable EPDM foam mat Recycled glass-filled nylon feet Salt spray tested to 1000 hours Order information: Product: Big Foot Multi Frame XL Extension – 1500x1200 mm – 2x330 mm Foot Article code: BFS-1228-000 External dimensions: L1500 x W1200 mm Weight: 34 kg EAN: 5414618006753 SKU: 10425840000 OEM: BN9732 Unit: Pc. Minimum order quantity: 1 Pc. Brand: Big Foot Systems Product group: A The Big Foot Multi Frame XL Extension provides a durable, flexible, and high-quality solution for extending flat roof mounting systems.

The Big Foot Multi Frame XL is an extremely robust and flexible mounting system for flat roofs. It has been developed for quick and easy installation and ensures maximum stability as well as unrestricted roof usability – even when installed. Thanks to the three integrated crossbars and the infinitely expandable design on both sides, the system can be optimally adapted to different requirements. Each support foot is individually height-adjustable and removable if required, allowing precise alignment even on uneven roof surfaces. The large footplates ensure even load distribution and protect the roof surface. With a maximum load capacity of 500 kg the Multi Frame XL is ideally suited for demanding applications. Inclined anti-vibration mats as well as a higher construction version are optionally available to meet additional requirements. Technical features: Easy installation Extremely robust construction 3 crossbars Infinitely expandable from both sides Roof remains fully functional Individually height-adjustable and removable feet Foot dimensions (L x W): 305 x 305 mm Height adjustment: 335–440 mm Maximum load: 500 kg Threaded rod: M24 Optional: increased construction (height adjustment 335–660 mm) Optional: inclined anti-vibration mats Order information: Product: Big Foot Multi Frame XL (boxed) Dimensions: 1500 x 1200 mm Feet: 4 x 305 mm Article code: BFS-1515-000 Weight: 43 kg EAN: 5414618981616 SKU: 10371320000 OEM: B9731 Unit: Pc. Minimum order quantity: 1 Pc. Brand: Big Foot Systems Product group: A The Big Foot Multi Frame XL stands for a future-proof, durable and flexible mounting solution of the highest quality.

The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system. Scope of Services Working time: Total 20 hours of team effort (2 technicians) Travel: up to 300 km (one way) Accomodation: included Material delivery: ordered units, components, installation sets delivered curbside Installation: indoor and outdoor units including piping System check: pressure test, vacuum, leak test, and functional run Commissioning: complete documented handover in operational condition Instruction: operation, basic functions, and maintenance guidance Additional services to be ordered separately Electrical connection (fuse connection, RCD/MCB, repair switch) Additional kilometers beyond 300 km Overnight costs for longer distances or multi-day assignments Special work (core drilling, wall penetrations, pipe adjustments) Condensate pump, funnel siphon, or connection to existing lines Connection or integration with Wifi or KNX Provision of scaffolding from 2 m working height, crane transport, lifts Provision of special tools and equipment for dismantling Construction and follow-up work: masonry, painting, roofing, and similar trades This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.

The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system. Scope of Services Working time: Total 16 hours of team effort (2 technicians) Travel: up to 60 km (one way) Material delivery: ordered units, components, installation sets delivered curbside Installation: indoor and outdoor units including piping System check: pressure test, vacuum, leak test, and functional run Commissioning: complete documented handover in operational condition Instruction: operation, basic functions, and maintenance guidance Additional services to be ordered separately Electrical connection (fuse connection, RCD/MCB, repair switch) Additional kilometers beyond 60 km Overnight costs for longer distances or multi-day assignments Special work (core drilling, wall penetrations, pipe adjustments) Condensate pump, funnel siphon, or connection to existing lines Connection or integration with Wifi or KNX Provision of scaffolding from 2 m working height, crane transport, lifts Provision of special tools and equipment for dismantling Construction and follow-up work: masonry, painting, roofing, and similar trades This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.

The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system. Scope of Services Working time: Total 12 hours of team effort (2 technicians) Travel: up to 30 km (one way) Material delivery: ordered units, components, installation sets delivered curbside Installation: indoor and outdoor units including piping System check: pressure test, vacuum, leak test, and functional run Commissioning: complete documented handover in operational condition Instruction: operation, basic functions, and maintenance guidance Additional services to be ordered separately Electrical connection (fuse connection, RCD/MCB, repair switch) Additional kilometers beyond 30 km Overnight costs for longer distances or multi-day assignments Special work (core drilling, wall penetrations, pipe adjustments) Condensate pump, funnel siphon, or connection to existing lines Connection or integration with Wifi or KNX Provision of scaffolding from 2 m working height, crane transport, lifts Provision of special tools and equipment for dismantling Construction and follow-up work: masonry, painting, roofing, and similar trades This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.

The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system. Scope of Services Working time: Total 14 hours of team effort (2 technicians) Travel: up to 30 km (one way) Material delivery: ordered units, components, installation sets delivered curbside Installation: indoor and outdoor units including piping System check: pressure test, vacuum, leak test, and functional run Commissioning: complete documented handover in operational condition Instruction: operation, basic functions, and maintenance guidance Additional services to be ordered separately Electrical connection (fuse connection, RCD/MCB, repair switch) Additional kilometers beyond 30 km Overnight costs for longer distances or multi-day assignments Special work (core drilling, wall penetrations, pipe adjustments) Condensate pump, funnel siphon, or connection to existing lines Connection or integration with Wifi or KNX Provision of scaffolding from 2 m working height, crane transport, lifts Provision of special tools and equipment for dismantling Construction and follow-up work: masonry, painting, roofing, and similar trades This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.

The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system. Scope of Services Working time: Total 20 hours of team effort (2 technicians) Travel: up to 400 km (one way) Accomodation: included Material delivery: ordered units, components, installation sets delivered curbside Installation: indoor and outdoor units including piping System check: pressure test, vacuum, leak test, and functional run Commissioning: complete documented handover in operational condition Instruction: operation, basic functions, and maintenance guidance Additional services to be ordered separately Electrical connection (fuse connection, RCD/MCB, repair switch) Additional kilometers beyond 400 km Overnight costs for longer distances or multi-day assignments Special work (core drilling, wall penetrations, pipe adjustments) Condensate pump, funnel siphon, or connection to existing lines Connection or integration with Wifi or KNX Provision of scaffolding from 2 m working height, crane transport, lifts Provision of special tools and equipment for dismantling Construction and follow-up work: masonry, painting, roofing, and similar trades This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.

The BIMcare™ Consumables Package for a Combined Supply and Exhaust Air Unit is an optional addition to BIMcare™ maintenance. It provides predictable costs, audit-proof documentation, and supports compliance with operator obligations for your ventilation systems. Objective Ensure hygienic and cost-efficient operation of ventilation systems through the use of approved consumables according to VDI 6022. Included Materials Disposable face masks, gloves, protective clothing All-purpose cleaners, disinfectants for heat exchangers and surfaces Cleaning cloths (disposable and reusable), sponges, drying cloths, trash bags Brushes, lamella combs, vacuum bags according to VDI 6022 Marking, sealing, and labeling materials for maintenance points Not Included Special air filters or standard filters for multi-stage systems Drive belts Extensive mold removal or hygiene/special measures External lab costs or special sampling/testing materials, additional personnel Delivery only in conjunction with BIMcare maintenance.

The BIMcare™ Consumables Package for Air Conditioning is an optional addition to BIMcare™ maintenance. It enables predictable costs, audit-proof documentation, and supports compliance with operator obligations for your air conditioning and ventilation systems. Objective Ensuring hygienic and cost-efficient operation of air conditioning systems through the use of standard consumables. Included Materials Filter materials (fine filters, activated carbon filters) Disinfectants and cleaning agents for split-type indoor and outdoor units Marking, sealing, and labeling materials for maintenance schedule Disposable gloves, cleaning cloths, and functional test materials Not Included Renovation or replacement of air conditioning units Extensive mold removal or special measures External lab costs or special testing equipment, e.g., for leak detection Delivery only in conjunction with BIMcare maintenance.

With BIMcare™, you get a modern, digital maintenance solution for your ventilation systems, supply and exhaust units, air filters, heat recovery, fire dampers, and steam humidifiers. Book flexibly online – no long contracts, no signature marathon. Why is a digital maintenance contract easier for my ventilation systems? You avoid long, complicated contracts and gain full transparency. With BIMcare™, you simply select online: desired duration, number of ventilation units, optional warranty extensions. No hidden clauses, no paperwork, full control over your systems. How do I order maintenance step by step? 1. Select duration from the dropdown (once-off, 24, 36, 48 or 48+ months). 2. Select unit type (e.g., ventilation unit, fire damper, steam humidifier, duct network). 3. Enter number of units. 4. Add to cart and complete order. Note: Price applies per unit. Summer maintenance can be optionally added. What is included in the maintenance price – and what is not? The booking covers scheduled maintenance of the selected units. Not included: Travel costs, Spare parts, Small materials, Repairs outside maintenance. These are usually provided by your facility manager. Optional bundle packages will be available in the future. How do I keep track of my maintenance dates? Your scheduled maintenance visits are automatically stored in your CAFM system. You can view the planned service month online at any time – no calls and no paperwork. BIMcare™ considers maintenance as a continuous process: Our technicians check your system for wear or visible fault causes and provide a clear action plan. On request, we perform necessary repairs or replacements professionally, ensuring your warranty remains valid and the system operates reliably. In short: You will receive access data after ordering BIMcare™ maintenance package. Use myBranchtool now When does maintenance take place? Regular maintenance ensures smooth operation. Ideally performed between May and October. Maintenance Intervals Unit Type Spring Summer* Autumn Ventilation Unit xxx Fire Damper x-- Steam Humidifier x-- Duct Network x-- *) Summer maintenance is optional and can be added. What warranty applies to my equipment? Standard warranty is 6 months from installation. With 48plus™, it can be extended up to 48 months – for worry-free operation of your ventilation systems. How do I plan materials and spare parts? Materials and spare parts are typically provided by your facility manager. Alternatively, you can use BIMpilot™, BIMdepot™, or BIMservice™. Full bundle packages will be available in the future.

We take care of your climate control systems, heat pumps, cold rooms and chilled-water installations. Without complex contracts, you receive simple and reliable inspection and maintenance services. Why is a digital maintenance contract for HVAC systems so beneficial? Due to missing maintenance and the current shortage of skilled technicians, service support in case of failure is often unreliable – and breakdowns usually occur in peak summer or winter. With BIMcare™, you avoid precisely these issues: no long-term commitments, fully flexible and predictable. We detect and eliminate typical sources of failure from the beginning and ensure safe, trouble-free operation. This makes BIMcare™ economical, sustainable and ideal for any building. How do I order a digital maintenance contract? Select the contract duration Choose the system type, e.g. indoor AC unit Enter the number of units Extend the warranty with 48plus if desired BIMcare™ maintenance ends automatically once the selected term expires. New maintenance orders can be placed at any time. What services are included? Depending on the system type, maintenance takes place at fixed, seasonally optimal times. This ensures energy efficiency, hygiene and high operational safety. Maintenance Intervals System Type Spring Summer* Autumn Air Conditioning Unit x x x Chiller - x x Chilled Water Network - x x Refrigeration Machine x x x Heat Pump x - x *) Summer maintenance is optional and not included in the BIMcare™ contract. How long is my system covered? With 48plus, you receive an extended all-round protection package. The standard 6-month warranty after installation can be extended to up to 48 months. How do I keep track of my maintenance dates? Your scheduled maintenance visits are automatically stored in your CAFM system. You can view the planned service month online at any time – no calls and no paperwork. BIMcare™ considers maintenance as a continuous process: Our technicians check your system for wear or visible fault causes and provide a clear action plan. On request, we perform necessary repairs or replacements professionally, ensuring your warranty remains valid and the system operates reliably. In short: You will receive access data after ordering BIMcare™ maintenance package. Use myBranchtool now Which costs are not included? This is not an all-inclusive offer. Costs for repairs, travel, spare parts, consumables and required tools are usually provided by our Facility Manager or available via BIMpilot™, BIMdepot™ or BIMservice™.
