Insulated Twin-Ferrule 6 mm² 26 mm yellow DIN 46228-4 tinned
€22.30*
Available, delivery time: 2-7 days
Product information "Insulated Twin-Ferrule 6 mm² 26 mm yellow DIN 46228-4 tinned"
The insulated twin ferrule 6 mm² according to DIN 46228-4 is used for secure joining of two fine-stranded conductors in electrical installations. Tin-plated copper ensures reliable corrosion protection and stable electrical connections.
The halogen-free polypropylene insulation sleeve provides additional mechanical strength and standardized yellow color coding.
Technical Data
- Nominal cross-section: 2x6 mm²
- Length: 26 mm
- Standard: DIN 46228-4
- Conductor material: Cu-DHP
- Surface: tinned
- Insulation material: PP
- Halogen-free: yes
- Color: yellow
- Temperature resistance: up to 105 °C
Scope of Delivery
- 100 pcs bag
| Cable - Core Dimension: | 6.0 mm² |
|---|
