Coolenvi™ SDI-System 4 Way Ceiling Cassette – 7.10/8.0 kW A+++ Heat Pump
€5,787.45*
% €7,145.00* (19% saved)Available, delivery time: May - October
Product number:
DE-ZT-CE08014WKAS+A.1
Product information "Coolenvi™ SDI-System 4 Way Ceiling Cassette – 7.10/8.0 kW A+++ Heat Pump"
SDI 4-way ceiling cassettes provide a powerful, elegant, and service-friendly solution for air conditioning in commercial, office, and technical spaces with suspended ceilings. From a ceiling height of approx. 3.5 m, they ensure even air distribution in all four directions and deliver high thermal comfort with efficient operation.
Thanks to flush integration into suspended ceilings, room design remains fully flexible: wall surfaces stay clear and usable floor space is optimally preserved. The low installation height of only approx. 26–32 cm allows installation even where ceiling voids are limited. For retrofits, all connection lines can be discreetly routed within the existing ceiling.
For grid ceilings, compact Euro-ceiling variants are also available—depending on unit size—allowing seamless integration into standard ceiling systems. SDI 4-way ceiling cassettes are designed for year-round operation and are also suitable for reliable cooling of IT and technical rooms.
Your benefits at a glance
- Even 4-way air distribution for high room comfort
- Reliable operation down to −15 °C outdoor temperature
- Low installation height of approx. 26–32 cm
- Flexible room layout thanks to free wall and floor areas
- Suitable for IT and technical room cooling
- Control of up to 16 systems with one remote control (depending on the control concept)
- Consistently high energy efficiency (energy class A)
All models feature a modular design and can be individually expanded with comprehensive control, regulation, and monitoring kits.
Add items for complete systems:
48plus warranty extension to 48 months (one-time fee per indoor unit – only in conjunction with BIMcare™).
LCD wired remote controller
Control option signal module (operation/fault indication and remote on/off) (only in conjunction with wired remote controller)
Installation SET 3 m / 5 m / 10 m / 15 m or 20 m, consisting of: mounting brackets, connection lines, and accessories
GSM KIT remote transmission of SMS notifications
Add services for installation:
Coolenvi – air conditioning installation fixed-price packages
Wall drilling
Electrical connection installation, including safety switch or fuse
Condensate drain installation or pump, funnel trap, etc.
Roof works, typically with scaffolding, flat-roof outlet
Increase of refrigerant charge
Programming of setpoint limitation
Programming of automatic restart after power failure
Ideal for:
Retail areas, retail stores, supermarkets, grocery markets, checkout zones, open-plan offices, shop premises, chain gastronomy, workshops, small-parts warehouses for sensitive goods, IT departments, small server rooms with limited space up to approx. 150 m², with a maximum sensible cooling capacity of up to 9.0 kW.
| SDI - Nominal Cooling Capacity kW: | 7,10 / 1,90 - 8,00 min.-max. |
|---|---|
| SDI - Nominal Heating Capacity kW: | 8,00 / 1,30 - 11,30 min.-max. |
| SDI - Consumption kW: | 0,41/2,38/3,09 |
| SDI - Power Supply V/Ph/Hz: | 220-240/1/50 |
| SDI - Energy Class: | A+++ cool / A+++ heat |
| SDI - Sound pressure level dB(A): | I 28/31/35 - O 48 |
| SDI - Pipe dimension mm (inch) / m: | 9,5 (3/8) - 15,9 (5/8) / 3 - 50 |
| SDI - Pipe Length (min.-max.) m: | 5 - 50 |
| SDI - Height Difference (max.) m: | 30 |
| SDI - IU Dimensions (HxWxD) mm: | 256 x 840 x 840 (30 x 950 x 950 Panel) |
| SDI - OU Dimensions (HxWxD) mm: | 1050 x 1010 x 370 - 801 |
| SDI - Weight IU/OU kg: | 30 / 74 |
| SDI - Refrigerant: | R32 |
Login
Others also ordered
New
Coolenvi™ - Mounting SET 10m I/O Commercial Devices
€929.85*
Item - Connection Length:
10m
|
Item - Installation SET Variant:
For Facades > 3.5kW
Installation set for small and large split air conditioning systems, primarily for commercial use, consisting of the following components in the specified quantities and for a maximum nominal capacity of approx. 12 kW.
Installation Set – Basic Equipment:
DE-WU0862104001 – 4x M8 quick connectors
DE-WU04223830 – 4x M8 rubber washers
DE-WU04168 – 4x M8 housing washers
DE-WU0057850 – 4x M8x40 machine screws
DE-WU0892143 – 1x PURLOGIC® mounting foam
DE-WU0892165 – 1x white acrylic sealant – 310 ml
DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml
DE-WU05021413 – 12x cable ties KBL 1 made of polyamide with plastic tongue
DE-HS1001 – 10 m control cable 5 x 1.5 mm
DE-WU097366090 – 10 m cable duct 60 x 90 mm, white
DE-HS760002001 – 10 m PVC-U pipe 20 mm
DE-HS760010001 – 1x PVC-U elbow 20 mm 90°
DE-HS240016001 – 1x Tangit adhesive
DE-WU0176204560 – 30x TX screws 4.5x60 mm
DE-WU590620635 – 32x wall plugs 6 mm
DE-WU0176203535 – 2x TX screws 3x35 mm
DE-S321.4016 – 10 m CU double pipe 10, 16 mm insulated
DE-S282.0541 – 2x solder fittings 10 mm
DE-S282.0543 – 2x solder fittings 16 mm
1x nitrogen soldering gas (flat rate) content, sealant
Installation Set Variant 1 – For facades from 3.5 kW cooling capacity:
DE-WU0862009062 – 2x wall brackets 630 mm
DE-WU0862005006 – 2x end caps
DE-WU0862009125 – 2x support beams 45°
DE-WU0862005326 – 2x holding clamp M10
DE-WU005791040 – 2x hex screws M10
DE-WU037110 – 2x hex lock nuts M10
DE-WU041610 – 4x body washers M10
DE-WU590681266 – 6x universal wall plugs 12 mm
DE-WU019210100 – 6x hex screws M10x100
DE-WU041610 – 6x washers M10
Installation Set Variant 2 – For floor or flat roof installation:
DE-WU0862003056 – 2x roof support beams 1000 mm
DE-WU071392915 – 2x construction site protective mats (strips)
Variants from €926.59*
New
Coolenvi™ - Mounting SET 15m I/O Commercial Devices
€1,174.21*
Item - Connection Length:
15m
|
Item - Installation SET Variant:
For Facades > 3.5kW
Installation set for small and large split air conditioning units, primarily for commercial use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW.
Installation Set – Basic Equipment:
DE-WU0862104001 – 4x M8 quick couplings
DE-WU04223830 – 4x M8 rubber washers
DE-WU04168 – 4x M8 housing washers
DE-WU0057850 – 4x M8x40 machine screws
DE-WU0892143 – 1x PURLOGIC® mounting foam
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml
DE-WU05021413 – 12x cable ties KBL 1 polyamide with plastic tongue
DE-HS1001 – 15 m control cable 5 x 1.5 mm²
DE-WU097366090 – 15 m cable trunking 60 x 90 mm, white
DE-HS760002001 – 15 m PVC-U pipe 20 mm
DE-HS760010001 – 1x PVC-U elbow 20 mm 90°
DE-HS240016001 – 1x Tangit adhesive
DE-WU0176204560 – 40x TX screws 4.5x60mm
DE-WU590620635 – 42x wall plugs 6mm
DE-WU0176203535 – 2x TX screws 3x35mm
DE-S321.4016 – 15 m CU double pipe 10,16mm insulated
DE-S282.0541 – 2x solder fittings 10mm
DE-S282.0543 – 2x solder fittings 16mm
1x nitrogen soldering gas (flat rate), sealant included
Installation Set Variant 1 – For facades from 3.5 kW cooling capacity:
DE-WU0862009062 – 2x wall brackets 630mm
DE-WU0862005006 – 2x end caps
DE-WU0862009125 – 2x support bars 45°
DE-WU0862005326 – 2x retaining clips M10
DE-WU005791040 – 2x hex screws M10
DE-WU037110 – 2x hex lock nuts M10
DE-WU041610 – 4x fender washers M10
DE-WU590681266 – 6x universal wall plugs 12 mm
DE-WU019210100 – 6x hex screws M10x100
DE-WU041610 – 6x washers M10
Installation Set Variant 2 – For floor or flat roof mounting:
DE-WU0862003056 – 2x roof support beams 1000mm
DE-WU071392915 – 2x construction protection mats (strips)
Variants from €1,170.95*
New
Coolenvi™ - Mounting SET 20m I/O Commercial Devices
€1,420.16*
Item - Connection Length:
20m
|
Item - Installation SET Variant:
For Facades > 3.5kW
Installation set for small and large split air conditioning units, primarily for commercial use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW.
Installation Set – Basic Equipment:
DE-WU0862104001 – 4x M8 quick couplings
DE-WU04223830 – 4x M8 rubber washers
DE-WU04168 – 4x M8 housing washers
DE-WU0057850 – 4x M8x40 machine screws
DE-WU0892143 – 1x PURLOGIC® mounting foam
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml
DE-WU05021413 – 20x cable ties KBL 1 polyamide with plastic tongue
DE-HS1001 – 20 m control cable 5 x 1.5 mm²
DE-WU097366090 – 20 m cable trunking 60 x 90 mm, white
DE-HS760002001 – 20 m PVC-U pipe 20 mm
DE-HS760010001 – 1x PVC-U elbow 20 mm 90°
DE-HS240016001 – 1x Tangit adhesive
DE-WU0176204560 – 50x TX screws 4.5x60mm
DE-WU590620635 – 52x wall plugs 6mm
DE-WU0176203535 – 2x TX screws 3x35mm
DE-S321.4016 – 20 m CU double pipe 10,16mm insulated
DE-S282.0541 – 2x solder fittings 10mm
DE-S282.0543 – 2x solder fittings 16mm
1x nitrogen soldering gas (flat rate), sealant included
Installation Set Variant 1 – For facades from 3.5 kW cooling capacity:
DE-WU0862009062 – 2x wall brackets 630mm
DE-WU0862005006 – 2x end caps
DE-WU0862009125 – 2x support bars 45°
DE-WU0862005326 – 2x retaining clips M10
DE-WU005791040 – 2x hex screws M10
DE-WU037110 – 2x hex lock nuts M10
DE-WU041610 – 4x fender washers M10
DE-WU590681266 – 6x universal wall plugs 12 mm
DE-WU019210100 – 6x hex screws M10x100
DE-WU041610 – 6x washers M10
Installation Set Variant 2 – For floor or flat roof mounting:
DE-WU0862003056 – 2x roof support beams 1000mm
DE-WU071392915 – 2x construction protection mats (strips)
Variants from €1,416.90*
New
Coolenvi™ - Mounting SET 3m I/O Commercial Devices
€585.77*
Item - Connection Length:
3m
|
Item - Installation SET Variant:
For Facades > 3.5kW
Mounting kit for small and large split air conditioning systems, mostly for commercial applications, consisting of the following individual components in the corresponding quantities and up to a maximum rated output of the air conditioning systems of approximately 12kW.
Installation kit – basic equipment:
DE-WU0862104001 – 4x M8 quick-release fasteners
DE-WU04223830 – 4x M8 rubber washers
DE-WU04168 – 4x M8 housing washers
DE-WU0057850 – 4x M8x40 machine screws
DE-WU0892143 – 1x PURLOGIC® Easy mounting foam
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU0892165 – 1x acrylic sealant white – 310 ml
DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml
DE-WU05021413 – 6x cable ties KBL 1 made of polyamide with plastic tongue
DE-HS1001 – 3 m control cable 5 x 1.5 mm
DE-WU097366090 – 3 m cable duct 60 x 90 mm, white
DE-HS760002001 – 3 m PVC-U pipe 20 mm
DE-HS760010001 – 1x PVC-U angle 20 mm, 90°
DE-HS240016001 – 1x Tangit glue
DE-WU0176204560 – 20x TX screws 4.5x60mm
DE-WU590620635 - 20x dowels 6mm
DE-WU0176203535 - 2x TX screws 3x35mm
DE-S321.4016 - 3m CU double pipe 10, 16mm insulated
DE-S282.0541 - 2x soldering sockets 10mm
DE-S282.0543 - 2x soldering sockets 16mm
1x Flat-rate nitrogen content, soldering gas content, sealant
Mounting kit variant 1 - For facades above 3.5 kW cooling capacity:
DE-WU0862009062 - 2x wall brackets 630mm
DE-WU0862005006 - 2x end caps
DE-WU0862009125 - 2x Support 45 degrees
DE-WU0862005326 - 2x Holding clamp
DE-WU005791040 - 2x hex screw M10
DE-WU037110 - 2x Lock nut hex M10
DE-WU590681266 - 6x universal wall anchors 12 mm
DE-WU019210100 - 6x hexagon head screws M10x100
DE-WU041610 - 6x washers M10
Mounting Kit Variant 2 - For floor or flat roof mounting:
DE-WU0862003056 - 2x Roof Support Beams 1000mm
DE-WU071392915 - 2x Construction Site Protection Mats in Strips
New
Coolenvi™ - Mounting SET 5m I/O Commercial Devices
€688.50*
Item - Connection Length:
5m
|
Item - Installation SET Variant:
For Facades > 3.5kW
Installation set for small and large split air conditioning systems, primarily for residential use, consisting of the following individual components in the specified quantities and for a maximum nominal capacity of approx. 12 kW.
Installation Set – Basic Equipment:
DE-WU0862104001 – 4x M8 quick connectors
DE-WU04223830 – 4x M8 rubber washers
DE-WU04168 – 4x M8 housing washers
DE-WU0057850 – 4x M8x40 machine screws
DE-WU0892143 – 1x PURLOGIC® mounting foam
DE-WU0892165 – 1x white acrylic sealant – 310 ml
DE-WU08925102 – 1x neutral silicone sealant WHITE – 310 ml
DE-WU05021413 – 6x cable ties KBL 1 made of polyamide with plastic tongue
DE-HS1001 – 5 m control cable 5 x 1.5 mm
DE-WU097366090 – 5 m cable duct 60 x 90 mm, white
DE-HS760002001 – 5 m PVC-U pipe 20 mm
DE-HS760010001 – 1x PVC-U elbow 20 mm 90°
DE-HS240016001 – 1x Tangit adhesive
DE-WU0176204560 – 30x TX screws 4.5x60 mm
DE-WU590620635 – 32x wall plugs 6 mm
DE-WU0176203535 – 2x TX screws 3x35 mm
DE-S321.4046 – 5 m CU double pipe 6, 12 mm insulated
DE-S282.0540 – 2x solder sleeves 6 mm
DE-S282.0542 – 2x solder sleeves 12 mm
1x nitrogen soldering gas (flat rate) content, sealant
Installation Set Variant 1 – For facades from 3.5 kW cooling capacity:
DE-WU0862009062 - 2x wall bracket 630 mm
DE-WU0862005006 – 2x end caps
DE-WU0862009125 - 2x support beams 45°
DE-WU0862005326 - 2x holding clamp M10
DE-WU005791040 - 2x hex screw M10
DE-WU037110 - 2x hex lock nut M10
DE-WU041610 - 6x body washers M10
DE-WU590681266 – 6x universal wall plugs 12 mm
DE-WU019210100 – 6x hex screws M10x100
DE-WU041610 – 6x washers M10
Installation Set Variant 2 – For floor or flat roof installation:
DE-WU0862003056 – 2x roof support beams 1000 mm
DE-WU071392915 – 2x construction site protective mats (strips)
Variants from €685.24*
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×10h | 100 km travel – Delivery | Setup | Commissioning | Handover
€2,600.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 20 hours of team effort (2 technicians)
Travel: up to 100 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 100 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×10h | 150 km travel – Delivery | Setup | Commissioning | Handover
€2,800.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 20 hours of team effort (2 technicians)
Travel: up to 150 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 150 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×10h | 200 km travel – Delivery | Setup | Commissioning | Handover
€3,150.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 20 hours of team effort (2 technicians)
Travel: up to 200 km (one way)
Accomodation: included
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 200 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
Coolenvi™ AC Installation – 1 AT | 2×6h | 30 km travel – Delivery | Setup | Commissioning | Handover
€1,440.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 12 hours of team effort (2 technicians)
Travel: up to 30 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 30 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×7h | 30 km travel – Delivery | Setup | Commissioning | Handover
€1,660.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 14 hours of team effort (2 technicians)
Travel: up to 30 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 30 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×8h | 30 km travel – Delivery | Setup | Commissioning | Handover
€1,880.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 16 hours of team effort (2 technicians)
Travel: up to 30 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 30 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
Tip
New
Coolenvi™ AC Installation – 1 AT | 2×8h | 60 km travel – Delivery | Setup | Commissioning | Handover
€2,000.00*
Task - Work Location:
DK - From Ribe
The installation package includes the deployment of a two-person service team for a full working day, as well as a single round trip from our service hub. It provides a clearly defined, professional solution for the installation of your air conditioning system.
Scope of Services
Working time: Total 16 hours of team effort (2 technicians)
Travel: up to 60 km (one way)
Material delivery: ordered units, components, installation sets delivered curbside
Installation: indoor and outdoor units including piping
System check: pressure test, vacuum, leak test, and functional run
Commissioning: complete documented handover in operational condition
Instruction: operation, basic functions, and maintenance guidance
Additional services to be ordered separately
Electrical connection (fuse connection, RCD/MCB, repair switch)
Additional kilometers beyond 60 km
Overnight costs for longer distances or multi-day assignments
Special work (core drilling, wall penetrations, pipe adjustments)
Condensate pump, funnel siphon, or connection to existing lines
Connection or integration with Wifi or KNX
Provision of scaffolding from 2 m working height, crane transport, lifts
Provision of special tools and equipment for dismantling
Construction and follow-up work: masonry, painting, roofing, and similar trades
This ensures a structured, efficient, and professional installation with a clearly defined scope of services. Installation is carried out according to ChemKlimaschutzV, EU 573/2024 and only by certified personnel or HVAC specialists.
